Typical Application:
Vacuum Cleaner
Power Tools
Massager
Vending Machine
Printer
Annunciator
Paper Shredder
Drill & Screw Driver
More…
| RS-550/555（TECHNICAL PARAMETER） | ||||||||||
| Model | Voltage | No Load | At Max. Efficiency | Stall Torque | ||||||
| Operating Range（V） | Nominal | Speed | Current | Speed | Current | Torque | Output | Eff | ||
| V | r.p.m | A | r.p.m | A | g.cm | W | % | g.cm | ||
| RS-550S-7524 | 4.5 ~ 12.0 | 12 | 23300 | 1.26 | 20000 | 8.9 | 360 | 73.91 | 69.2 | 2542 |
| RS-550S-6530 | 3.0 ~ 12.0 | 9.6 | 14200 | 0.73 | 11900 | 6.9 | 370 | 45.2 | 68.2 | 2284 |
| RS-550S-5050 | 6.0 ~ 24.0 | 7.2 | 6400 | 0.42 | 5400 | 2.65 | 230 | 12.75 | 66.8 | 1472 |
| RS-550S-4070 | 6.0 ~ 30.0 | 12 | 7550 | 0.35 | 6550 | 2.3 | 280 | 18.83 | 68.2 | 2114 |
| RS-550S-3780 | 6.0 ~ 30.0 | 6 | 3300 | 0.24 | 2780 | 1.27 | 165 | 4.71 | 61.8 | 1047 |
| RS-555S-3550 | 9.0 ~ 30.0 | 12 | 4800 | 0.17 | 4240 | 1.3 | 262 | 11.4 | 68.7 | 2246 |
| RS-555S-2960 | 6.0 ~ 30.0 | 24 | 9500 | 0.28 | 8150 | 1.7 | 360 | 30.12 | 73.8 | 2533 |
| RS-555S-2670 | 12.0 ~ 30.0 | 12 | 4500 | 0.19 | 3680 | 0.88 | 160 | 6.04 | 57.2 | 878 |
| RS-555S-2195 | 9.6-14.4 | 12 | 3190 | 0.13 | 2460 | 0.54 | 200 | 5.050235294 | 77.93572985 | 876 |
| RS-555S-2962 | 9.6-14.4 | 12 | 5000 | 0.21 | 4200 | 1.1 | 200 | 8.622352941 | 65.32085561 | 1135 |
| RS-555S-2398 | 12-27.4 | 24 | 4850 | 0.19 | 4150 | 0.85 | 330 | 14.05751471 | 68.90938581 | 2200 |
| RS-550S-5930 | 9.6-14.4 | 12 | 19900 | 1.1 | 16870 | 5.37 | 250 | 43.29139706 | 67.18093895 | 1600 |
| RS-550S-5930 | 12~24 | 18 | 28900 | 1.45 | 24450 | 5.9 | 250 | 62.74301471 | 59.08005151 | 2400 |
| RS-550S-5928 | 9.6-14.4 | 12 | 18200 | 1.3 | 15700 | 6.7 | 250 | 40.28897059 | 50.11065994 | 2180 |
