Typical Application:
Toys
Massagers
Mini Fans
Tooth Brushes
Electric Shavers
Motorized Plastic Models
Automotive Mirrors
More…
| FF-130（TECHNICAL PARAMETER） | ||||||||||
| Model | Voltage | No Load | At Max. Efficiency | Stall Torque | ||||||
| Operating Range（V） | Nominal | Speed | Current | Speed | Current | Torque | Output | Eff | ||
| V | r.p.m | A | r.p.m | A | g.cm | W | % | g.cm | ||
| FF-130S-2365 | 1.5 ~ 3.0 | 3 | 13500 | 0.28 | 10900 | 1.06 | 12 | 1.342623529 | 42.2208657 | 60 |
| FF-130-2365 | 1.5 ~ 3.0 | 3 | 18000 | 0.32 | 14140 | 1.17 | 10 | 1.451429412 | 41.35126529 | 45 |
| FF-130S-18100 | 1.5 ~ 3.0 | 3 | 9300 | 0.16 | 7270 | 0.57 | 10 | 0.746244118 | 43.64000688 | 50 |
| FF-130-18100 | 1.5 ~ 3.0 | 3 | 13000 | 0.21 | 9800 | 0.62 | 8 | 0.804752941 | 43.26628716 | 32 |
| FF-130S-15160 | 3.0 ~ 6.0 | 4.5 | 8800 | 0.16 | 6500 | 0.46 | 13.5 | 0.900727941 | 43.51342711 | 50 |
| FF-130-15160 | 3.0 ~ 6.0 | 4.5 | 11800 | 0.17 | 8700 | 0.48 | 8 | 0.714423529 | 33.0751634 | 30 |
| FF-130-12220 | 3.0 ~ 6.0 | 3 | 6100 | 0.055 | 4420 | 0.14 | 3.5 | 0.158795 | 37.80833333 | 13 |
| FF-130S-10300 | 4.5 ~ 15.0 | 12 | 12000 | 0.085 | 9050 | 0.26 | 14.5 | 1.346986029 | 43.17262915 | 60 |
| FF-130S-09350 | 6.0 ~ 15.0 | 12 | 10800 | 0.07 | 8000 | 0.2 | 14 | 1.149647059 | 47.90196078 | 55 |
| FF-130S-08450 | 6.0 ~ 15.0 | 12 | 7200 | 0.05 | 5150 | 0.14 | 12 | 0.634358824 | 37.75945378 | 42 |
