Typical Application:
Toys
Massagers
Mini Fans
Tooth Brushes
Electric Shavers
Motorized Plastic Models
More…
| RS-140（TECHNICAL PARAMETER） | ||||||||||
| Model | Voltage | No Load | At Max. Efficiency | Stall Torque | ||||||
| Operating Range（V） | Nominal | Speed | Current | Speed | Current | Torque | Output | Eff | ||
| V | r.p.m | A | r.p.m | A | g.cm | W | % | g.cm | ||
| RS-140S-2365 | 1.5 ~ 3.6 | 3 | 12000 | 0.28 | 9630 | 1.13 | 15 | 1.482736765 | 43.73854763 | 75 |
| RS-140-2270 | 1.5 ~ 3.0 | 1.5 | 8400 | 0.22 | 6400 | 0.7 | 22 | 1.445270588 | 137.6448179 | 27 |
| RS-140-2270 | 1.5 ~ 3.0 | 3 | 14500 | 0.27 | 11200 | 1.02 | 11 | 1.264611765 | 41.32718185 | 50 |
| RS-140-18100 | 1.5 ~ 3.0 | 1.5 | 5800 | 0.15 | 4320 | 0.39 | 5 | 0.221717647 | 37.90045249 | 17 |
| RS-140-18100 | 1.5 ~ 3.0 | 3 | 11000 | 0.18 | 8300 | 0.6 | 8.5 | 0.724175 | 40.23194444 | 35 |
| RS-140-14150 | 1.5 ~ 4.5 | 3 | 7300 | 0.1 | 5400 | 0.29 | 6 | 0.332576471 | 38.22718053 | 22 |
| RS-140-14150 | 1.5 ~ 4.5 | 4.5 | 10800 | 0.13 | 8200 | 0.4 | 9 | 0.757535294 | 42.08529412 | 35 |
| RS-140-12220 | 3.0 ~ 7.2 | 3 | 5100 | 0.06 | 3400 | 0.16 | 5 | 0.1745 | 36.35416667 | 17 |
| RS-140-10300 | 3.0 ~ 7.2 | 3 | 3700 | 0.04 | 2600 | 0.1 | 3.5 | 0.093408824 | 31.13627451 | 12 |
| RS-140-10300 | 3.0 ~ 7.2 | 6 | 7600 | 0.06 | 5500 | 0.16 | 6.5 | 0.366963235 | 38.22533701 | 22 |
