Typical Application:
Electric Shavers
Massagers
Tooth Brushes
CD/VCD Player
Record Player
Automotive Central Locking System
More…
| FF-180（TECHNICAL PARAMETER） | ||||||||||
| Model | Voltage | No Load | At Max. Efficiency | Stall Torque | ||||||
| Operating Range（V） | Nominal | Speed | Current | Speed | Current | Torque | Output | Eff | ||
| V | r.p.m | A | r.p.m | A | g.cm | W | % | g.cm | ||
| FF-180S-4022 | 1.0 ~ 1.5 | 1.2 | 9000 | 0.5 | 7320 | 2.1 | 18.5 | 1.390046471 | 55.16057423 | 100 |
| FF-180S-3530 | 1.0 ~ 2.4 | 1.5 | 8300 | 0.32 | 6650 | 1.3 | 15.5 | 1.058034559 | 54.2581825 | 80 |
| FF-180S-3240 | 1.0 ~ 2.4 | 2.4 | 10500 | 0.32 | 8570 | 1.42 | 25 | 2.199213235 | 64.53090479 | 135 |
| FF-180S-2760 | 1.5 ~ 3.0 | 2.4 | 6800 | 0.16 | 5600 | 0.7 | 18 | 1.034682353 | 61.58823529 | 100 |
| FF-180S-2658 | 1.5 ~ 3.0 | 2.4 | 7200 | 0.16 | 5900 | 0.73 | 17 | 1.02955 | 58.76426941 | 92 |
| FF-180S-2572 | 1.5 ~ 6.0 | 2 | 4700 | 0.15 | 3650 | 0.6 | 17 | 0.636925 | 53.07708333 | 80 |
| FF-180S-2295 | 1.5 ~ 6.0 | 3 | 5500 | 0.11 | 4400 | 0.45 | 20 | 0.903294118 | 66.91067538 | 100 |
| FF-180S-1590 | 3.0 ~ 7.2 | 6 | 11000 | 0.2 | 8150 | 0.75 | 25 | 2.091433824 | 46.47630719 | 85 |
| FF-180S-10300 | 6.0 ~ 15.0 | 12 | 6780 | 0.04 | 5450 | 0.15 | 18 | 1.006967647 | 55.94264706 | 85 |
