Typical Application:
Massagers
Toys
Hair Dryer
Motorized Plastic Models
Mini Fans
Can Openers
Water Pump
Mini Cleaners
Automotive Rearview Mirror
Automotive Central Locking System
RS-370(TECHNICAL PARAMETER) | ||||||||||
Model | Voltage | No Load | At Max. Efficiency | Stall Torque | ||||||
Operating Range(V) | Nominal | Speed | Current | Speed | Current | Torque | Output | Eff | ||
V | r.p.m | A | r.p.m | A | g.cm | W | % | g.cm | ||
RS-370-27100 | 1.0 ~ 4.5 | 3 | 5150 | 0.055 | 4500 | 0.4 | 18 | 0.831441176 | 69.28676471 | 145 |
RS-370-25120 | 1.5 ~ 6.0 | 4.5 | 6250 | 0.09 | 5300 | 0.48 | 25 | 1.360073529 | 62.9663671 | 160 |
RS-370-21170 | 1.5 ~ 6.0 | 6 | 6000 | 0.055 | 5250 | 0.35 | 23 | 1.239463235 | 59.02205882 | 185 |
RS-370-17315 | 2.4 ~ 9.0 | 6 | 3250 | 0.035 | 2700 | 0.17 | 20 | 0.554294118 | 54.34256055 | 115 |
RS-370-17315 | 2.4 ~ 9.0 | 9 | 4900 | 0.04 | 4150 | 0.42 | 27 | 1.150160294 | 30.42752101 | 175 |
RS-370-15370 | 3.0 ~ 15.0 | 12 | 5500 | 0.03 | 4700 | 0.165 | 26 | 1.254347059 | 63.35086156 | 180 |
RS-370-12560 | 4.5 ~ 15.0 | 12 | 3700 | 0.02 | 3050 | 0.1 | 22 | 0.688761765 | 57.39681373 | 130 |
RS-370-11670 | 6.0 ~ 18.0 | 12 | 3060 | 0.016 | 2500 | 0.07 | 20 | 0.513235294 | 61.09943978 | 110 |
RS-370-10750 | 6.0 ~ 24.0 | 13 | 2800 | 0.013 | 2300 | 0.06 | 18.5 | 0.436763235 | 55.99528658 | 100 |
RS-370-08780 | 9.0 ~ 30.0 | 12 | 2500 | 0.01 | 2000 | 0.04 | 13.2 | 0.270988235 | 56.45588235 | 65 |
