典型用途
电吹风
爆谷机
按摩器
自动售货机
打印机
报警器
水泵
打蛋器
其它驱动装置
| RS-360/365电机技术参数（TECHNICAL PARAMETER） | ||||||||||
| 规格型号 | 电压 | 空载 | 最大效率时的负载特性 | 堵载力矩 | ||||||
| 使用范围（V） | 标称值 | 转速 | 电流 | 转速 | 电流 | 力矩 | 输出 | 效率 | ||
| V | r.p.m | A | r.p.m | A | g.cm | W | % | g.cm | ||
| RS-360S-4528 | 1.5 ~ 6.0 | 2.4 | 11000 | 1.1 | 8500 | 2.6 | 42 | 3.6645 | 58.72596154 | 156 |
| RS-360S-3548 | 2.4 ~ 9.0 | 9 | 25000 | 0.8 | 20500 | 3.85 | 88 | 18.51752941 | 53.44164332 | 500 |
| RS-360S-3165 | 1.2 ~ 6.0 | 3.6 | 8500 | 0.39 | 6800 | 1.62 | 50 | 3.49 | 59.84224966 | 260 |
| RS-360S-25110 | 3.0 ~ 15.0 | 6 | 8400 | 0.22 | 6900 | 1.05 | 55 | 3.895455882 | 61.83263305 | 320 |
| RS-360S-10500 | 9.0 ~ 30.0 | 24 | 7200 | 0.055 | 5600 | 0.2 | 46 | 2.644188235 | 55.0872549 | 220 |
| RS-360S-15120 | 6.0 ~ 24.0 | 24 | 14850 | 0.13 | 11931 | 0.62 | 90 | 11.02213853 | 74 | 470 |
| RS-365S-3133 | 2.4 ~ 9.0 | 4.5 | 11500 | 0.45 | 9300 | 1.81 | 50 | 4.773088235 | 58.60145163 | 240 |
| RS-365S-2840 | 3.0 ~ 12.0 | 12 | 24000 | 0.47 | 19800 | 2.24 | 75 | 15.24308824 | 56.70791754 | 430 |
| RS-365S-2172 | 6.0 ~ 24.0 | 20 | 22000 | 0.28 | 18600 | 1.4 | 100 | 19.09235294 | 68.18697479 | 365 |
| RS-365S-1980 | 6.0 ~ 24.0 | 24 | 24000 | 0.2 | 20800 | 1.35 | 95 | 20.28305882 | 62.60203341 | 500 |
| RS-365S-10225 | 6.0 ~ 36.0 | 24 | 8100 | 0.065 | 6200 | 0.22 | 43 | 2.736570588 | 51.82898841 | 180 |
| RS-360S-08810 | 12-27.6 | 24 | 4050 | 0.04 | 3100 | 0.12 | 40 | 1.272823529 | 44.19526144 | 168 |
| RS-360S-08780 | 12-27.6 | 24 | 4500 | 0.045 | 3150 | 0.15 | 40 | 1.293352941 | 35.92647059 | 130 |
| RS-365S-1974 | 12-27.6 | 16 | 17800 | 0.25 | 14500 | 1.13 | 73 | 10.86519118 | 60.09508394 | 398 |
| RS-360S-12385 | 12-27.6 | 24 | 9600 | 0.09 | 7790 | 0.48 | 63 | 5.037609706 | 43.72925092 | 300 |
| RS-360S-12315 | 6.0 ~ 14.4.0 | 12 | 5600 | 0.13 | 4300 | 0.36 | 52 | 2.295188235 | 53.1293573 | 240 |
