Typical Application:
Hair Dryer
Popcorn Maker
Massager
Vending Machine
Printer
Annunciator
Water Pump
Egg Mixer
More…
| RS-380/385（TECHNICAL PARAMETER） | ||||||||||
| Model | Voltage | No Load | At Max. Efficiency | Stall Torque | ||||||
| Operating Range（V） | Nominal | Speed | Current | Speed | Current | Torque | Output | Eff | ||
| V | r.p.m | A | r.p.m | A | g.cm | W | % | g.cm | ||
| RS-380S-4530 | 1.5 ~ 6.0 | 6 | 19500 | 0.9 | 16500 | 5.23 | 110 | 18.63044118 | 59.37043077 | 600 |
| RS-380S-3548 | 2.4 ~ 6.0 | 3.6 | 8600 | 0.54 | 6880 | 2.15 | 60 | 4.237270588 | 54.74509804 | 300 |
| RS-380S-3270 | 4.5 ~ 12.0 | 12 | 17500 | 0.35 | 14750 | 2.15 | 100 | 15.14044118 | 58.68388053 | 620 |
| RS-380S-2580 | 6.0 ~ 18.0 | 12 | 16800 | 0.26 | 14318 | 1.5 | 80 | 11.75760471 | 65.32002614 | 550 |
| RS-380S-15200 | 6.0 ~ 24.0 | 12 | 6700 | 0.11 | 5360 | 0.44 | 50 | 2.750941176 | 52.10115865 | 250 |
| RS-385S-2365 | 4.5 ~ 24.0 | 17.5 | 15800 | 0.19 | 13400 | 1.1 | 95 | 13.06697059 | 67.88036669 | 610 |
| RS-385S-2173 | 6.0 ~ 26.0 | 24 | 22120 | 0.21 | 18750 | 1.17 | 100 | 19.24632353 | 68.54103821 | 660 |
| RS-385S-2173 | 6.0 ~ 26.0 | 18 | 15600 | 0.26 | 13200 | 1.1 | 91 | 12.32996471 | 62.27254902 | 583 |
| RS-385S-1980 | 4.5 ~ 30.0 | 5 | 3445 | 0.11 | 2630 | 0.35 | 38 | 1.025854706 | 58.62026891 | 160 |
| RS-385S-17120 | 6.0 ~ 30.0 | 24 | 12000 | 0.12 | 10100 | 0.63 | 83 | 8.604902941 | 56.91073374 | 520 |
| RS-385S-10250 | 9.0 ~ 30.0 | 24 | 5800 | 0.04 | 4610 | 0.16 | 45 | 2.129413235 | 55.45346967 | 220 |
| RS-385S-21115 | 6.0 ~ 18.0 | 12 | 11000 | 0.25 | 8850 | 1.05 | 84 | 7.630782353 | 60.56176471 | 428 |
| RS-385S-15128 | 9.0 ~ 30.0 | 24 | 10900 | 0.14 | 8720 | 0.85 | 88 | 7.876724706 | 38.61139562 | 448 |
| RS-385S-2385 | 9.0 ~ 30.0 | 18 | 20000 | 0.35 | 16700 | 1.45 | 90 | 15.42785294 | 59.11054767 | 500 |
| RS-385S-3131 | 9.0 ~ 30.0 | 18 | 35000 | 0.65 | 30500 | 3 | 100 | 31.30735294 | 57.97657952 | 700 |
| RS-385S-2083 | 27.4-35 | 30 | 17400 | 0.68 | 15300 | 0.85 | 120 | 18.846 | 73.90588235 | 1120 |
| RS-380S-3365 | 4.8-7.2 | 6 | 10500 | 0.5 | 8500 | 2.1 | 88 | 7.678 | 60.93650794 | 450 |
| RS-380S-1973 | 6.0 ~ 18.0 | 12 | 15300 | 0.26 | 13200 | 101 | 91 | 12.32996471 | 1.017323821 | 583 |
