Typical Application:
Hair Dryer
Popcorn Maker
Massager
Vending Machine
Printer
Annunciator
Water Pump
Egg Mixer
More…
| RS-380/385（TECHNICAL PARAMETER） | ||||||||||
| Model | Voltage | No Load | At Max. Efficiency | Stall Torque | ||||||
| Operating Range（V） | Nominal | Speed | Current | Speed | Current | Torque | Output | Eff | ||
| V | r.p.m | A | r.p.m | A | g.cm | W | % | g.cm | ||
| RS-395-3325 | 2.4 ~ 12.0 | 6 | 10200 | 0.41 | 8461 | 1.99 | 87 | 7.56 | 63.3 | 510 |
| RS-395-2840 | 6.0 ~ 18.0 | 12 | 13500 | 0.25 | 11624 | 1.55 | 113.3 | 13.52 | 72.7 | 815 |
| RS-395S-2168 | 6.0 ~ 30.0 | 12 | 6850 | 0.135 | 5712 | 0.68 | 87.2 | 5.11 | 62.7 | 525 |
| RS-395S-1965 | 6.0 ~ 30.0 | 24 | 14500 | 0.15 | 12520 | 0.95 | 122.9 | 15.79 | 69.3 | 900 |
| RS-395S-1890 | 9.0 ~ 30.0 | 24 | 10500 | 0.11 | 8800 | 0.63 | 112.5 | 10.16 | 67.2 | 780 |
| RS-395-17120 | 9.0 ~ 30 | 12 | 4023 | 0.05 | 3337 | 0.25 | 58.9 | 2.02 | 67.8 | 345 |
| RS-395S-15150 | 9.0 ~ 30 | 24 | 6200 | 0.055 | 5255 | 0.31 | 96 | 5.18 | 69.6 | 630 |
| RS-395-15120 | 9.0 ~ 30 | 24 | 7721 | 0.07 | 6263 | 0.3 | 72.7 | 4.67 | 64.9 | 385 |
| RS-395S-14100 | 9.0 ~ 30 | 24 | 9100 | 0.095 | 7549 | 0.46 | 88.6 | 6.87 | 62.2 | 520 |
| RS-395-10230 | 9.0 ~ 30 | 24 | 4077 | 0.032 | 3232 | 0.12 | 51.8 | 1.72 | 6.3 | 250 |
| RS-395-45 | 40-50 | 45 | 11000 | 0.15 | 9400 | 0.65 | 220 | 21.22741176 | 72.57234791 | 1400 |
